Suitable fitment for all Ariel Models that
use this 7” Single Sided Front Brake
with the Conical Small Flange
Devon / Dunlop Part Code
19″ WM2 = AA15
20″ WM1 = AA16
21″ WM1 = AA16-1-21
Ariel WM2 X 19
42419-34, 42519-34, 42219-34, 4502-34
Ariel WM1 X 20
42420-34, 42520-34, 42220-34, 4503-34
WM1 X 21
4504-34
Chrome Rims Plated AFTER Hole Punching
Dimple Pattern = 3×1 .250 Nipple Holes
Spokes are 10 Gauge 3.2mm
10 x 10 gauge Bent to Brake Side Inner Specification
10 x 10 gauge Bent to Brake Side Outer Specification
20 x 10 gauge Bent to Small Conical Flange Specification
40 x 10 gauge .250″ Brass Nickel Plated Nipple
Ariel Spoke Part Codes
19″ = 4546-36, 4532-46
20″ = 4531-36, 4537-51
21″ = 4546-11, 4532-11
OEM ref numbers given are by no means exhaustive, we understand some manuals list differing numbers depending on Year & Model but be assured, provided you have selected the correct Hub and Rim diameter, these items will suit your application.
All our Wheel Rims & Spokes are 100% MADE IN ENGLAND not imported, modified and then passed off as such. Rims are Manufactured to a “Tru” Dunlop profile as used back in the day. We & many 1000s of customers simply say they are “The Best Wheel Rims Money Can Buy” All our Spokes are made from premium grade 304 Stainless Steel at 950 – 1050 N/mm2 to OEM specifications and bends. We only use U.K. sourced wires NOT Far East imports.
Devon Rolltru Premium Mirror Stainless
Manufactured from 2.0mm (WM2 & WM3) & 1.5mm (WM1) 304 2b Superior Grade Stainless Steel, Individually Hand Welded prior to Roll Forming so making the weld virtually undetectable, Then we polish them to a “Tru” Mirror finish that looks as good as Chrome but without the fear of rust. Most people can’t tell the difference. Pierced to OEM specifications, these Rims really are as good as it gets!
Devon Rolltru Diamond British Chrome
Manufactured on the same machinery by the same craftsmen right here in Devon, as are all our Wheel Rims, then unlike most of our competition, pierced to OEM specifications BEFORE being Triple Plated to Service Condition 4 British Chrome. Generally aimed at the high end & museum quality resto.
Devon Valtru Standard Stainless Steel
Manufactured to the same specifications as our Premium Stainless Rims but at a fraction of the cost to you. How do we do this, the answer is simple. POLISHING, it takes time , a lot of it. So these Rims are finished to a functional level that saves you ££££s. Still pierced to OEM specifications.
Devon Valtru Standard British Chrome
Still 100% Made In England but we’ve saved a lot of time on the polishing again. Still British Triple Chromed to Service Condition 4 and as with all our Chrome Rims the Piercing is done BEFORE plating and to OEM specification.
